Stealth-Cat

From the pipe rack to the drill floor, AGODCO Catwalk Systems enable a “hands-off” approach to Tubular Running Services (TRS). The TRS is not only safer and simplified, with the STEALTH-CAT_T100™ you can speed productivity to astonishing results as it has a maximum tubular string length of 100ft whilst still being able to run single tubes. The Top Drive elevator takes over the tubular lifting as the Triple Catwalk offers the tubes right up to the drill floor. Temporary storage of the tubulars in the mouse hole is no longer necessary and this again decreases handling and drives up productivity.

PRODUCT OFFERINGS

      KEY FEATURES



  • sequence assisted controls
  • hydraulic pipe racks
  • hydraulic levelling system
  • onboard electric HPU
  • wireless remote control
  • integrates with conveyors

OPTIONAL FEATURES



  • adjustable rig floor height
  • conventional V-Door
  • cold weather package
  • kicker indexer interface
  • kicker skate interface

KEY BENEFITS



  • accelerates TRS
  • reduces hazards & risk
  • fast rig-up time
  • reduces drilling costs
  • increases productivity
  • reduces GHG emissions

Productivity Increases

  • Can deliver up to 300% daily increase of tubular goods delivered to the drill floor compared to single Catwalk systems.
  • Increased material delivery drives up productivity values such as drilling costper-foot whilst increasing daily footage drilled on each rig.

The STEALTH-CAT_T100™ comes in two modular skid units and its tray for ease of assembly, disassembly, and transportation. All the AGODCO CATWALK units come supplied with wireless remote-control units that are Ex-Rated Class 1, Div 2 providing additional operator safety values.

Catwalk TRS Systems

The AGODCO Group is a leading energy related industrial manufacturer of value innovative technologies. Our hydraulic catwalks in tandem with our conveyor systems and other Tubular Running Services equipment, result in higher productivity, lower hazard, and risk, whilst contributing to the bottom-line performance of TRS, Drilling Companies. The STEALTH-CAT_T100™ was specifically designed and fabricated to meet the productivity and safety needs of some of the biggest players in drilling. The design utilised the best technologies and stress analysis together 3-D modelling. The “Triple” refers to the extraordinary capacity to load a string of 3 tubulars to the rig floor at any one time delivering up to 100 ft in one lifting cycle whilst still running singles if needed. Our catwalks are designed for fast rig-up and rig down and we also offer a range for optional equipment including the Skid Walking System for finite alignment.
